WPLR系列行星减速机

产品特点

1.行星臂架与输出轴采用一体式结构设计，确保最大的扭转刚性。

2.行星轮采用满滚针设计，增加接触面积以提高结构刚性与输出扭矩。

3.齿轮采用低碳钢表面渗碳淬火到HRC62,以获得最佳的耐磨及冲击韧性。

4.齿形引用国外进口软件辅助设计，以获得最佳的齿形降低噪音。

5.输入端与马达轴连接采用双边抱紧方式，以获取最大的夹紧力和零背隙的动力传递。

6.采用蜗线伞齿轮设计，容许输出扭矩高、比直伞齿轮高30%以上。

7.高容许输入转速，比直伞齿轮输入高8倍以上。

8.蜗线伞齿轮的啮合齿印，经最佳优化设计，接触齿面负载均一，运转寿命长。

9.蜗线伞齿轮啮合，经最佳运动误差分析与严格的制程控制，以确保高精度的运转背隙。

Features

1.Planetary boom and output shaft are intergrated structure designed to ensure maximum torsional rigidity.

2.Planetary wheel with full needle design,increase the contact area to improve the rigidity and output torque.

3.The gears are carburized and quenched to the HRC62 with low carbon steel surface for optimum wear and impact toughness.

4.Gears refer to foreign imported software assisted design to obtain the best tooth shape to reduce noise.

5.The input terminal is connected to the motor shaft in a double-tight manner to obtain the maximum clamping force and zero backlash power transmission.

6.Adopt spiral bevel gear design, allow high output torque,more than 30% higher than straight bevel gear.

7.High tolerance input speed, more than 8 times higher than straight bevel gear input.

8.The meshing tooth imprint of spiral bevel gear has been optimized by optimum design, and the contact tooth surface load is uniform, and long running life.

9.Cochlear bevel gears are meshed by optimum motion error analysis and strict process control to ensure high precision running back clearance.
