WABR系列行星减速机

产品特点

1.行星臂架与输出轴采用一体式结构设计，确保最大的扭转刚性。

2.行星轮采用满滚针设计，增加接触面积以提高结构刚性与输出扭矩。

3.齿轮采用低碳钢表面渗碳淬火到HRC62，以获得最佳的耐磨及冲击韧性。

4.齿形引用国外进0软件辅助设计，以获得最佳的齿形降低噪音。

5.输入端与马达轴连接采用双边抱紧方式，以获取最大的夹紧力和零背隙的动力传递。

Features

1.Planetary boom and output shaft are intergrated structure designed to ensure maximum torsional rigidity.

2.Planetary wheel with full needle design,increase the contact area to improve the rigidity and output torque.

3.The gears are carburized and quenched to the HRC62 with low carbon steel surface for optimum wear and impact toughness.

4.Gears refer to foreign imported software -assisted design to obtain the best tooth shape to reduce noise.

5.The input terminal is connected to the motor shaft in a double-tight manner to obtain the maximum clamping force and zero

backlash power transmission.
